Discriminating Interstitial Sensor

Discriminiating Interstitial Sensor is designed for use in a double-wall fiberglass tank to detect the presence of fluid and distinguish between fuel and water. Sensor will also alarm if the cable to the sensor breaks or if the sensor malfunctions.

All DFS sensors are designed to be multi-dropped during installation, eliminating the need for a dedicated wiring home-run for each sensor. Built with our proprietary IntelliSense technology, sensors will automatically self-identify with serial number and model number, making installation simple.

Part Number: FM30-0234-HW-01

Application: Interstitial space of double-wall fiberglass tank

Differentiates: Fuel vs. water Product

Detection: Requires min. 0.10 in (0.25 cm) fuel to activate

Operating Temp: -40°F to 150°F (-40°C to 66°C)
